Feature:
1.Portable and compact
2.Suitable for multiple appliances
3.Intelligent frequency conversion energy saving and fuel saving
4.Intelligent operation control panel
Precautions for using a generator:
1.Preheating and idling:
When the engine temperature is low,the idling time should be appropriately extended for preheating,but when the temperature is normal,avoid long-term idling to avoid carbon deposits and oil leakage inthe turbocharger and exhaust system.The load should be between 30%and 70%of the generatorpower.
2.Avoid overload:
Do not let the generator run overloaded for a long time,which will cause failures and shorten theservice life.
3.Maintenance and operation safety:
It is strictly forbidden to disassemble or replace parts while the generator is running to preventaccidenta injuries
4.Coolant and antifreeze:
Choose appropriate coolant or antifreeze according to the season and temperature,and pay attentionto check the status of the water tank to avoid injuries caused by high-temperature liquid spraying.
5.Fuel management:
Make sure to use fuel that meets the standards,be sure to turn off the generator when refueling,anddon't smoke or approach open flames when refueling to prevent fuel overflow.
6.Check before starting:
Check the fuel and oil levels before starting,ensure that the oil circuit is unobstructed and air-free,andconnect the battery line and control module.
7.Fuel supply adjustment:
Be careful when adjusting the fuel supply to avoid unstable operation or damage to the engine due toexcessive fuel supply.Follow the comparison method for fine adjustment.
8.Environment and location:
Place the generator in a well-ventilated location away from flammable materials.Avoid using it in adusty environment to prevent malfunctions.
9.Fire safety:
Understand and prepare appropriate fire extinguishing measures.In the event of a fire,follow specificemergency procedures,such as not using sand or foam fire extinguishers to directly extinguish the generator.
10.Regular maintenance:
Perform regular inspections and maintenance according to the maintenance cycle recommended bythe manufacturer,including replacing filters,engine oil,etc.,to ensure that the generator is in the bestcondition.
Byfollowing the above precautlons,you can ensure the efficlent safe and long-termrellable operatilon ofthe sflent generator.
Technical Data
| Model |
1500KC |
2750KC |
3000KC |
3500KC |
| Voltage |
DC 12V |
DC 24V |
DC 24V |
DC 24V |
| Rated output |
1.0kw |
1.8kw |
2.0kw |
2.5kw |
| Max.output |
1.2kw |
2.0kw |
2.2kw |
2.8kw |
| Engine model |
148F-2 |
148F-2 |
152F-2 |
165F |
| Engine type |
Single Cylinder,4-stroke,Air Force Cooling,OHV |
| Displacement |
79.7cc |
79.7cc |
98cc |
149cc |
| Oil capacity |
0.45L |
0.45L |
0.45L |
0.55L |
| Starting system |
ecoil Start/Remote Start /Auto Start & Stop |
| Speed Control |
Double step electronic speed control |
| Noise |
<59db(A) |
<59db(A) |
<59db(A) |
<68db(A) |
| Fuel Tank |
5.5L |
6.5L |
6.5L |
7.5L |
| Continuousrunningtime(50%) |
11h |
12h |
12h |
11.5h |
| Net/gross weight |
19/21 |
20/22 |
20/22 |
22/24 |
| Package sizes(mm) |
530X355X535 |
530X355X535 |
545*355*540 |
540x355x570 |
| Loading quantity(20 GP /40 GP /40 HQ) |
284/572/715 |
276/588/735 |
5263/533/640 |
263/533/640 |
